Product details

Product features：

• High standard HVAC control applications, wall mounted and pipe mounted.

• High performance capacitive humidity sensor.

• Accuracy ± 0.2 ℃, ± 2% RH.

• The wall is installed with a hidden outlet on the back, which is beautiful and has dustproof and waterproof requirements.

• 2 wire system 4 … 20mA current output. beautiful and has dustproof and waterproof requirements.

• RS485 digital output is available.

• Show optional items.

• Support the calibration of on-site comparison equipment.

• Excellent long-term stability.

TR10 series temperature and humidity transmitters use independent platinum resistance thermometry and polymer film capacitance to measure humidity, enabling accurate relative humidity and temperature measurements in closed-loop control systems such as HVAC and cleanroom applications. Applications include wall and duct mounting, with an IP65 rating for use in wet areas. Each TR10 series transmitter is individually calibrated at the factory. If necessary, the transmitter can also be calibrated in situ using a PC with a reference. The new generation of TR10 temperature and humidity transmitter adds the design of hidden lead port on the back for wall installation, which is more in line with the aesthetic and protective requirements of large-scale modern indoor installation.

TR10 Series Temperature and Humidity Transmitter.pdf
